Baja Designs

LP4 Pro LED Auxiliary Light Pod Pair - Universal

LP4 Pro LED Auxiliary Light Pod Pair - Universal

SKU: 297814

$875.95
$875.95 $875.95
Shipping calculated at checkout.

34 in stock

Expected delivery date:
03 Sep Usually ready in 2-3 days.

Warranty Information

Product Details

Description

The Baja Designs LP4 Pro, the smallest variant in the LP lineup, maintains the power and features of its siblings. With a total of 8,857 lumens and a 200-degree spread of usable LED light, the LP4 delivers 6,885 forward-projecting lumens and 1,972 lumens of dedicated peripheral lighting through Integrated Peripheral Technology (IPT). To ensure optimal performance, the LP4 incorporates our proprietary Direct Ducted Cooling (DDC) technology, allowing efficient air circulation over the rear heat sinks. This significantly enhances cooling capacity and overall performance. The LP4 Pro offers customization with red, blue, or green backlight options in addition to the original amber, allowing enthusiasts to personalize their vehicle for shows, photo shoots, or wherever they seek attention.

Baja Designs LP series lights featuring red, blue, or green backlights are intended exclusively for exhibition use. Avoid usage on public roads to prevent confusion with law enforcement or emergency vehicles. The owner/driver bears the responsibility of adhering to all highway equipment laws and safety regulations.

Baja Advantage:

  • Satisfaction Guarantee - 30-Day Money Back Guarantee
  • Limited Lifetime Warranty - Complete Purchase Protection
  • uService - Replaceable Lenses And Optics
  • ClearView - All The Light, Right Where You Need It
  • MoistureBlock - Waterproof, Rain Proof, Submersible
  • CopperDrive - Safely Driving LEDs at 100 percent
  • 5000K Daylight - Less Driver Fatigue, Natural Color

Specs

LP4 Pro LED Auxiliary Light Pod
Product TypeLP4 Pro LED Light Pod Pair w/ Wiring Harness
Lighting Quantity4
Light Quantity2
Lighting ModesBeam / Day-Time Running Backlighting
Lighting TechnologyLED
Lighting TypeForward Projecting
Beam PatternDriving/Combo
Brightness (Lumens)8857
Wattage (W)75.900
Amperage Rating (A)5.500
Backlight Wattage (W)4.830
Backlight Amperage Rating (A)0.350
Secondary Lighting Quantity4 LEDs
Secondary Lighting TypeIntegrated Peripheral Technology (IPT)
Secondary Lighting TechnologyLED
Secondary Brightness (Lumens)1972
Secondary Wattage (W)15
Secondary Amperage Rating (A)1.000
Average Rated Life (hr.)49,930
Housing MaterialPowder Coat Cast Aluminum
Housing ColorBlack
Lens MaterialHardcoated Polycarbonate
Lens ColorClear
Bezel MaterialPowder Coat Cast Aluminum
Overvoltage ProtectionBuilt-In
Mounting Hardware IncludedYes
Mounting Hardware MaterialStainless Steel
Terminal ConnectorDT06-4S Deutsch
Terminal TypeMating Connector
Universal or SpecificUniversal

Fitment

Universal

GET TO KNOW THE LP SERIES

  • Direct Ducted Cooling (DDC)

    With so much power, a cooling system was an integral part of making the LP series perform at the highest level. Direct Ducted Cooling, or DDC has been designed in all of the LP series lights for exceptional heat dispersion. This acts as channels, allowing air to travel from the front of the housing to the rear heat sinks keeping the lights from overheating while in use.

  • Integrated Peripheral Technology (IPT)

    One of the features that makes the LP series the best on the trail is Integrated Peripheral Technology, or IPT for short. The IPTs allows the LP series to provide an incredible 200-degree spread of usable light, combining forward and cornering light in an all-in-one package.

  • Unique Design

    The unique Baja Designs futuristic styling through 3D light face with flat and sloping surfaces blended to the case offers the LP9, LP6 and LP4 a characteristic unlike any other light on the market today.

  • Color Backlight Options

    Our LP Pro series models offer color backlight options. Choose from amber, red, green, or blue giving enthusiasts the choice to customize their vehicles for shows, photo shoots, or anywhere they want to bring attention.

  • uService Lens Replacement

    Keeping the LP series running at the highest level means having a lens that is free of damage. All LP series lights have been designed with Baja Designs uService technology. Changing a damaged lens and customizing your light pattern is made easy as unscrewing the housing bolts in the back and installing a new lens. All this can be done in your garage or on the trail without the fear of voiding your Lifetime limited warranty.

Baja Designs LP Series - Inside Look
