47 Gallon Replacement Fuel Tank for 2007-2018 Mercedes Sprinter 144" and 170" Wheelbase
47 Gallon Replacement Fuel Tank for 2007-2018 Mercedes Sprinter 144" and 170" Wheelbase
SKU: SKU: 10-1024
16 in stock
Couldn't load pickup availability
Product Details
Description
Get Out and Stay Out. More Time to Explore.
S&B’s 47-Gallon Replacement Fuel Tank is a high-capacity, direct replacement for your factory 24-gallon tank. Designed to nearly double your driving range, this tank helps you go further and spend less time at the pump—perfect for long hauls, off-grid trips, and overland adventures.
PLUG AND PLAY INSTALLATION
The S&B Tank comes with all the components to remove your 24 gallon tank and replace it with our 40 gallon tank. The tank mounts in the stock location using the included straps. The tank occupies the space forward (13.1 inches) and rearward (3.3 inches) of the original tank.
YOUR FUEL GAUGE WORKS AS NORMAL
Even with more fuel on board, your fuel gauge will remain accurate thanks to S&B’s tank design. The gauge will stay on full for the first 5-7 gallons but then continue to move as normal. The distance to empty however will still be calculated based on the stock fuel capacity. For example, @ 20mpg and a full tank (40 gallons) you will have 800 miles to empty but your vehicle will show you have 480 miles to empty.
When using the auxiliary fuel tap on stock tanks, tap stops pulling fuel around 1/4 tank. With the S&B Tank, it will stop pulling fuel around 1/3-1/2 tank.
Important: The fuel gauge will only work accurately on vans with the J51 fuel gauge (optimized for aux. fuel tap). Please call your Mercedes dealer to confirm if you have this option. If you don’t have it, you will need TI1349-00.
Specs
| Replacement Fuel Tank | |
| Dimensions | 98.28" x 15.41" x 14.28" |
| Drain | No |
| Ground Clearance Compared to OE Tank | 1.5" |
| OEM Capacity | 24 Gallons |
| Sending Unit | OE |
| Straps Included | Yes |
| Sump | No |
| S&B Capacity (Approximate) | 47 Gallons |
| Tank Type | Midship |
| Weight (Dry) | 45 lbs |
Fitment
2007-2018 Mercedes Sprinter 3.0L Diesel
2007-2018 Mercedes Sprinter 2.0L Diesel
2009-2019 Coachmen Prism 3.0L Diesel
2010-2018 Forest River Solera 3.0L Diesel
This tank will NOT fit 170" Crew Vans or 144" Dually Vans, part # 10-1026 will work for the 170" Crew Vans and 144" Dually Vans. This tank will also not work with 144" vans that have ride height sensors connected to the rear axle, please see important note C on the instructions.
